V014-Stülpecke (28-90 mm)

V014-Stülpecke (28-90 mm)

V014-Stülpecke (28-90 mm)
V014-Stülpecke (28-90 mm)
Art. No. Colour Board thickness b Side length S Total width B Pad height h Material Packing unit Weight/ packing unit
V014-28/85-S black 28 mm 85 mm 32 mm 2 mm PE 1,000 pcs 17.4 kg
V014-28/85N natural 28 mm 85 mm 32 mm 2 mm PE 1,000 pcs 17.4 kg
V014-30/35-S black 30 mm 35 mm 33 mm 1.5 mm PE 3,000 pcs 14.1 kg
V014-30/35-N natural 30 mm 35 mm 33 mm 1.5 mm PE 3,000 pcs 14.1 kg
V014-30/50-S black 30 mm 50 mm 34 mm 2 mm PE 1,500 pcs 12.0 kg
V014-30/50-N natural 30 mm 50 mm 34 mm 2 mm PE 1,500 pcs 12.0 kg
V014-38/80-S black 38 mm 80 mm 41 mm 1.5 mm PE 800 pcs 10.3 kg
V014-38/80-N natural 38 mm 80 mm 41 mm 1.5 mm PE 800 pcs 10.3 kg
V014-40/58-S black 40 mm 58 mm 43 mm 1.5 mm PE 1,700 pcs 13.7 kg
V014-40/58-N natural 40 mm 58 mm 43 mm 1.5 mm PE 1,700 pcs 13.7 kg
V014-40/75-S black 40 mm 75 mm 43 mm 1.5 mm PE 900 pcs 15.4 kg
V014-40/75-N natural 40 mm 75 mm 43 mm 1.5 mm PE 900 pcs 15.4 kg
V014-42/100-S black 42 mm 100 mm 45 mm 1.5 mm PE 450 pcs 11.8 kg
V014-42/100-N natural 42 mm 100 mm 45 mm 1.5 mm PE 450 pcs 11.8 kg
V014-50/50-S black 50 mm 50 mm 53 mm 1.5 mm PE 900 pcs 10.3 kg
V014-50/50-N natural 50 mm 50 mm 53 mm 1.5 mm PE 900 pcs 10.3 kg
V014-90/45-S black 90 mm 45 mm 93 mm 1.5 mm PE 1,200 pcs 15.1 kg
V014-90/45-N natural 90 mm 45 mm 93 mm 1.5 mm PE 1,200 pcs 15.1 kg
Stülpecke V014 (28-90 mm)
